空气滤芯是一种过滤器，又叫空气滤筒、空气滤清器、风格等。主要用于工程机车、汽车、农用机车、实验室、无菌操作室及各种精密操作室中的空气过滤。发动机在工作过程中要吸进大量的空气，如果空气不经过滤清，空气中悬浮的尘埃被吸入气缸中，就会加速活塞组及气缸的磨损。较大的颗粒进入活塞与气缸之间，会造成严重的“拉缸”现象，这在干燥多沙的工作环境中尤为严重。空气滤清器装在化油器或进气管的前方，起到滤除空气中灰尘、砂粒的作用，保证气缸中进入足量、清洁的空气。

空气滤芯是一种过滤器，又叫空气滤筒、空气滤清器、风格等。主要用于工程机车、汽车、农用机车、实验室、无菌操作室及各种精密操作室中的空气过滤。发动机在工作过程中要吸进大量的空气，如果空气不经过滤清，空气中悬浮的尘埃被吸入气缸中，就会加速活塞组及气缸的磨损。较大的颗粒进入活塞与气缸之间，会造成严重的“拉缸”现象，这在干燥多沙的工作环境中尤为严重。空气滤清器装在化油器或进气管的前方，起到滤除空气中灰尘、砂粒的作用，保证气缸中进入足量、清洁的空气。

　　空气滤芯是一种过滤器，又叫空气滤筒、空气滤清器、风格等。主要用于工程机车、汽车、农用机车、实验室、无菌操作室及各种精密操作室中的空气过滤。　　发动机在工作过程中要吸进大量的空气，如果空气不经过滤清，空气中悬浮的尘埃被吸入气缸中，就会加速活塞组及气缸的磨损。较大的颗粒进入活塞与气缸之间，会造成严重的"拉缸"现象，这在干燥多沙的工作环境中尤为严重。空气滤清器装在化油器或进气管的前方，起到滤除空气中灰尘、砂粒的作用，保证气缸中进入足量、清洁的空气。　　

GS-Z蒸汽过滤器-高精度终端过滤器采用蒸汽消毒灭菌时，由于蒸汽管道系统内杂物较多，对高精度过滤介质带来严重后果，因此，对蒸汽必须进行过滤。GS-Z蒸汽过滤器高精度终端过滤器采用蒸汽消毒灭菌时，由于蒸汽管道系统内杂物较多，对高精度过滤介质带来严重后果，因此，对蒸汽必须进行过滤。我厂生产的GS-Z型系列蒸汽过滤器是高精度终端过滤器的配套产品，其主要作用是有效而可靠地除掉夹带在蒸汽中的杂质，保护和延长高精度终端过滤器的使用寿命。主要由壳体和滤芯组成，壳体为全不锈钢制造，其进出口在同一中心线上，拆卸上筒体即可更换滤芯；滤芯材质为聚四氟乙烯（粉末烧结），过滤精度1μm，具有耐高温、耐腐蚀、可再生处理等优点。应用户要求滤芯材质亦可采用钛金属或不锈钢纤维烧结毡。

Security filter is made of high quality imported 304 or 316L stainless steel, internally uses PP melt injection, wire burning, folding, titanium filter, activated carbon filter element as filter elements, select different filter elements according to different filter media and design processes to remove solid particles, bacteria and other impurities in the fluid to meet the requirements of water quality.Technical parameterDesign pressure: 0.75—1.6MpaDesign temperature: 20℃ ~120℃Sealed type: O-ring and flat cushionSeal material: nitrile rubber, silicone, fluorine rubber label, the standard configuration is silicone sealInterface form: tooth, clamp, GB, HG, DIN, ANSI, JIS standard flangesSuitable filter element: flat port, 222,226 socket filter elementSurface treatment: matte spray beads, mirror polishing, electrolytic polishingFilter accuracy: 0.1  μm- -150 μmMaterial: SUS304 316LProduct characteristics1. The equipment may do any horizontal or vertical structure according to the space.2 .Filter elements with any core number and accuracy can be selected according to the flow rate and accuracy requirements.3. The sealing partition of the filter element adopts CNC precision boring, which can ensure that there is no liquid bypass side leakage.4. The filter element inside and outside the filter element, can ensure that the filter element does not shake and tilt during operation, to ensure the sealing performance.5. Open The equipment quickly using the ring bolt, making it more convenient to maintain the equipment and replace the filter element.Application area1.Electronics, power station, microelectronics, semiconductor industry for high pure water security filtration, terminal filtration;2.Security filtration and terminal filtration, nano-filter (NF), ultrafiltration (UF), reverse osmosis (RO), electroseepage analysis (EDI) and other systems;3.Medical needles, large infusion, eye drops, Chinese herbal medicine medicine and other filtration, biological extraction, purification, enrichment;4.Oil field back to water injection, boiler supply water, chemical reagents, liquid organic products, high-purity chemicals, concentrated medicine and other filtration;5.Drink pure water, mineral water, fruit juice, tea drinks, health drink filtration;6.Filtering of white wine, wine, beer, yellow rice wine and other fruit wine, pure raw beer sterilization filtration;7.Pre-treatment and filtration or security filtration during production and domestic wastewater treatment and medium water recycling and reuse;8.All kinds of liquid filtration, clarification, purification treatment.

Security Filter, manufactured from premium imported 304 or 316L stainless steel. Internal tubular filter elements include PP melt-blown, wire-wound, pleated, titanium, and activated carbon cartridges. Filter elements are selected based on specific filtration media and design requirements to remove solid particles, bacteria, and other impurities from fluids, ensuring compliance with effluent quality standards.Technical ParametersDesign Pressure: 0.75–1.6 MPaDesign Temperature: 20°C–120°CSealing Type: O-ring and flat gasketSeal Material: Nitrile rubber, silicone rubber, fluororubber; standard configuration uses silicone sealsConnection Type: Threaded, clamp, GB, HG, DIN, ANSI, JIS standard flangesCompatible Cartridges: Flush-end, 222, 226 Socket CartridgesSurface Finish: Matte Shot-blasted, Mirror Polished, Electrolytic PolishedFiltration Accuracy: 0.1μm–150μmMaterial: SUS304, 316LProduct Features1. Equipment can be configured as horizontal or vertical structures based on space constraints.2. Optional filter elements with any number of cores and precision levels can be selected based on flow rate and accuracy requirements.3. The partition at the filter element sealing area is CNC precision-bored to guarantee zero liquid bypass leakage.4. Robust internal and external support ensures filter elements remain stable and aligned during operation, maintaining sealing integrity.5. Quick-release eye bolts enable rapid equipment access, simplifying maintenance and cartridge replacement.Application Fields1. Security and final filtration for high-purity water in electronics, power plants, microelectronics, and semiconductor industries;2. Security and final filtration for systems including nanofiltration (NF), ultrafiltration (UF), reverse osmosis (RO), and electrodialysis (EDI);3. Filtration of pharmaceutical injections, large-volume parenteral solutions, eye drops, and herbal medicine solutions; extraction, purification, and concentration of biological products;4. Filtration of oilfield reinjection water, boiler feedwater, chemical reagents, liquid organic preparations, high-purity chemicals, and concentrated pharmaceuticals;5. Filtration of drinking purified water, mineral water, fruit juices, tea beverages, and health drinks;6. Filtration of spirits, wine, beer, rice wine, and other fruit wines; sterilizing filtration for draft beer;7. Pre-treatment or security filtration in industrial and domestic wastewater treatment and recycled water reuse processes;8. Filtration, clarification, and purification of various liquids.

.

.

.

.

不锈钢精密过滤器：·不锈钢SUS304、SUS316材质·进出口径：1/2"、3/4"、1"、1.5"进出口径·配置排气阀、排污阀、固定挂板、拆卸扳手·适用: 10"PP、线绕、活性炭、折叠膜、不锈钢滤芯·设计流量：300-500L/min     ·适合压力：0.1-0.3MPa   ·功能：过滤、铁绣、泥砂、专用去除水垢等·滤除水中的颗粒性杂质，如铁绣，泥沙，颗粒物
